COM-1613 SELCAL ENCODER 120V/240V 50-60Hz

COM-1613 SELCAL ENCODER 120V/240V 50-60Hz

Product No.:
N1304B-1
Delivery:
Del 20 Days
Stock:
 Not in stock
Price Break 1 Stk
0,00  DKK
Quantity
Purchase

Tone generation and code selecting elements are combined in an attractive console that is designed for mounting in a 19” rack or on a desktop.

The N1304B-1 SELCAL encoder console includes the latest state-of-the-art tone sourcing that generates all 16 SELCAL frequencies.

ALT. PN: N1304A, CTS-700
In operation, the console operator simply selects the four-digit code assigned to the aircraft, confirms correct selection on the large alpha display, and momentarily presses the “SEND” button. Relay contacts within the unit can be wired to automatically key the base station, causing the selective signaling to be automatically transmitted.
The small size and weight of the unit makes it perfect for direct replacement of older 12 code units or installation in new facilities. Simply adding the rack mount adapters to the desktop housing allows the unit to be mounted in a 19” rack, only requiring 3.5 inches of panel space. Rack adapters are supplied with every unit.
The SELCAL encoder can be operated on 115/230 VAC 50/60 Hz and may be used worldwide without adapters or modifications. A terminal strip connection is provided within the unit for power connection.
